Fuel CNG














Gaspplicatio ns

TEDOM engines are based on well-established and, in the recent past, by far the most frequently used engine for trucks and buses in the Czech Republic. The engines have undergone substantial modifications for application in modern vehicles, while all their proven features have remained unchanged. TEDOM engines can be also used as a full replacement for LIAZ engines while vehicles are being repaired or converted to run on natural gas.


The CITY series of engines fulfils the emission limits of the EURO 5 and EEV standards.


We offer engines in horizontal as well as upright versions, as required by the customer.


For mobile applications (gas engines for buses or diesel engines for DMUs) we are one of the few producers, capable to offer also engines in horizontal version. Our horizontal engines with total high around 700mm are very suitable for under-floor installations.


CITY type engines














Gaspplications

Engine type

Stroke volume

Drilling / Stroke

Compression

Nominal capacity

Nominal speed

Maximum torque (Mt)

Speed at Mtmax.


dm3

mm

ratio

kW

min-1

Nm

min-1

CITY 180

11,946

130/150

13,0:1

180

2 200

883

1 200

CITY 210

11,946

130/150

11,1:1

220

2 000

1 146

1 600

CITY 250

11,946

130/150

11,1:1

260

2 000

1 354

1 600

Description of TEDOM engine marking system is available here.

or

You can download a leaflet on CITY CNG engines here.
